H100B230G
Specifications
| Alarm stages | 1 |
| Brand | E2S |
| CE certificate | Yes |
| Cable entry | 1x 5-7mm grommet |
| Certificates, quality marks, markings | CE, GOST-R, EAC |
| Colour | RAL 7038 grey |
| Dimensions | 86mm x 86mm x 85mm |
| Ingress protection | IP65 |
| Material | ABS |
| Model | Signal horn |
| Mounting type | Wall mounting |
| Number of tones | 3 |
| Operating temperature | -25°C to +50°C |
| Operating voltage | 48-230V AC/DC |
| Rated current | 48V DC 15mA / 115V DC 19mA / 240V AC 10mA |
| Rated voltage | 48-230V AC/DC |
| Relative humidity | Less than 90% (no condensation) at 20°C |
| Sound level (max.) | 100dB(A) @ 1m |
| Type | Pre-configured |
| Voltage | 48V |
| Voltage type | AC |
| Weight | 118g |
| Brand | E2S |
| Model | Signal horn |
| Voltage | 48V |
| Voltage type | AC |
| Rated voltage | 48-230V AC/DC |
| Rated current | 48V DC 15mA / 115V DC 19mA / 240V AC 10mA |
| Operating voltage | 48-230V AC/DC |
| Sound level (max.) | 100dB(A) @ 1m |
| Number of tones | 3 |
| Alarm stages | 1 |
| Ingress protection | IP65 |
| Operating temperature | -25°C to +50°C |
| Relative humidity | Less than 90% (no condensation) at 20°C |
| Dimensions | 86mm x 86mm x 85mm |
| Mounting type | Wall mounting |
| Cable entry | 1x 5-7mm grommet |
| Material | ABS |
| Weight | 118g |
| Colour | RAL 7038 grey |
| Certificates, quality marks, markings | CE, GOST-R, EAC |
| CE certificate | Yes |
| Type | Pre-configured |
Good to know
This electronic horn reproduces the classic buzzer sound very well.
