LED beacon, IP66, Ø150mm, 12-24V DC, terminal block, blue

• Brand
  • Patlite
• Voltage
  • 12V DC / 24V DC
• Rated voltage
  • 12-24V DC
• Rated current
  • 12V DC 0,40A / 24V DC 0,24A
• Operating voltage
  • 10-30V DC
• Buzzer
  • No
• LED life
  • 100 000h
• Colour lens
  • Yellow
• Luminous intensity
  • 220cd
• Light patterns
  • Steady, blinking and triple flash
• Particularities
  • Blinks 180x/minute or flashes 120x/minute
• Mounting and connection type
  • 3-point hole mounting/terminal block
• Ingress protection
  • IP66
• Operating temperature
  • -20°C to +50°C
• Impact resistance
  • 4,5G
• Relative humidity
  • Less than 90% (no condensation) at 20°C
• Dimensions
  • Ø150mm x 201mm
• Material
  • Polycarbonate
• Cable length
  • 500mm
• Weight
  • 860g
• Certificates, quality marks, markings
  • CE, cULus, EAC, KC
• UL certificate
  • Yes
• CE certificate
  • Yes
